該系列是一款360°全回轉手動驅動裝置。主要結合各種電裝配套使用，速比可根據開閥時間選配，常用于各類管網式閥門。適用于閘閥，截止閥，三通球閥、蝶閥、旋塞閥等閥門。箱體采用精密鑄造，樣式新穎，外形美觀。直齒輪傳動，使用推力軸承和深溝球軸承結合，傳動更加靈活，效率高。齒輪輪與閥門閥桿連接部分由實體和內置螺母兩款供客戶選擇，法蘭全部采用ISO5210國際標準，與閥門配套更加方便。防護等級為IP65.特殊環境還可做到IP68以及浸沒模式.
These are 360° turn gear actuators, working with electrical equipments, which ratio can be choosed by valve open time. They are suitable for gate valve, globe valve, T-Cock ball valves,butterfly valves, and plug valves etc.The housing is precisely cast, with fresh pattern and nice appearance. Transmit by spur gear, deep groove ball bearing and thrustl bearing combination makes the transmission more flexible and efficient. The connecting part of gear and valve stem can be uni-body or seperated optionally.The connectting flange adapts to I.S.O.5211 makes it easy working with valves.Protection grade can be IP65, IP68 and Immersion mode according to customers requirements.
e.型號大�。篔C4-0~JC4-6共7個尺寸供選擇，扭矩范圍300-4000Nm
|
|
